AD21/AD32/AD33
Watch Video
Popular search
Instantly adjust your diffusion level—smoothly and quickly shifting from hard shadows to ultra-soft illumination. Precise motorized control enables dynamic diffusion changes exactly when and how you need them, enhancing flexibility on set and expanding creative possibilities.
Powered via USB-C, V-mount batteries, or NPF batteries. Achieve up to 20 hours of continuous use at full load from a single 100Wh battery—covering even the longest shooting days.
Supports both Level Mode and Light Reduction Mode. Level Mode enables 0-100% visualized quick adjustments, providing intuitive diffusion control. Light Reduction Mode offers a -0.1 to -2.0 EV range, designed to match professional workflows.
Features patented frequency adjustment technology, supporting five frequency levels to ensure flicker-free operation tailored to different frame rates. Compatible with frame rates up to 300fps.
The collapsible frame ensures compact storage and rapid deployment. A removable, Velcro-attached diffusion panel allows convenient storage and quick replacement, featuring IP54-rated protection for reliable all-weather shooting.
Available in three sizes to accommodate various production needs.
Control it your way—both controllers support operation via controller, Bluetooth APP, and DMX. Additionally, the AD00-01 controller integrates a built-in CRMX transceiver, ensuring stable, low-latency wireless control. Lead/Follow mode lets one controller sync them all for smooth, unified adjustments on set.
Each size of the adjustable diffusion panel offers two controller options, letting users choose based on their specific workflow and daily needs.
Technical Data of the Controller
| Model | AD00-01 | AD00-02 |
| USB-C Port | lnput: 12V-20V⎓6.5A | Input: 5V⎓2A |
| AC Output Port | Output: 0V-28V ~ | Output: 0V-28V ~ |
| USB-A Port | Firmware Upgrade/5V⎓1.5A Power Supply | No USB-A Port |
| Controlling Methods | DMX/RDM, CRMX, Bluetooth app, controller control | DMX/RDM, Bluetooth app, controller control |
| Bluetooth Controlling Distance | 30m | 30m |
| Working Environment Temperature | -20℃~40℃ | -20℃~40℃ |
| Dimension≈ | 3.27"*1.81"*5.91" | 1.97"*1.42"*0.71" |
| Net Weight≈ | 259g | 160g |
Technical Data of the Adjustable Diffusion
| Model | AD21-01 | AD32-01 | AD33-01 |
| AC Input | 0V-28V~, 2W | 0V-28V~, 3W | 0V-28V~, 5W |
| Dimension≈ | 17.76"*23.7" | 25.04"*36.42" | 41.46"*39.61" |
| Net Weight≈ | 0.25kg | 0.5kg | 0.8kg |
