BP-19K/26K/36K-Product-GODOX Photo Equipment Co.,Ltd.

Built for High-Power Flat Bowens-Mount Lights

Made for high-power flat Bowens-mount lights, the BP-19K/26K/36K works seamlessly with KNOWLED M1000R/M600R/M600Bi Pro and future high-power flat Bowens-mount LED fixtures. It also supports LA600R/LA600Bi and other flat Bowens-mount fixtures under 1000W.

Stays Compact

Weighing just 5.4kg (main unit) + 2kg (lens), the BP-19K/26K/36K supports high-power flat Bowens-mount fixtures while maintaining a compact build and enabling effortless one-person setup. Engineered for efficient transportation and easy setup, it reduces operational effort—whether for overhead rigging or quick installation.

Intensify Beam Focusing with Precision

Boasting a significant illuminance boost, the BP-19K/26K/36K ensures efficient beam focusing. Its precision optics deliver a uniform beam with outstanding color rendering, maintaining consistent center - to - edge performance.

Cool Actively, Perform Steadily

With a built-in high-efficiency cooling fan connected to the light body via signal cable, and combined with its metal body and perforated ventilation design, the BP-19K/26K/36K ensures safe, stable operation even under intensive use of high-power fixtures.

Deliver Premium Beams, Ensure Sharp Focus

By utilizing a precision lens system paired with advanced optical design, the BP-19K/26K/36K delivers a consistently uniform light spot with sharp, well-defined edges for professional-grade results.

Rotate 360° Effortlessly

Supports 360° rotation, enabling effortless angle adjustment. The BP-19K/26K/36K can be moved quickly on set without removing the projection slide holder, boosting workflow efficiency.

Focus Dynamically, Create Freely

Featuring a focus knob for seamless and precise adjustments, the BP-19K/26K/36K effortlessly switches between sharp focus and background blur to maximize shooting versatility.

Three Lens Options

Available with 19°, 26°, and 36° lenses for different beam angles.

Shape Light, Unleash Creativity

Paired with versatile accessories- iris diaphragm, gobos, shutters, and gels -the BP Projection Attachment enables precise adjustments to beam shape, color, and size,Create spotlights, follows pots, and beam patterns, unlocking creative potential for dynamic visual storytelling.

Recommendation

Tech Specs

Specifications and Parameters

	Dimension≈	Net Weight≈
Projection	11.93"8.94"8.15"	5.4kg
Projection Lens 19°	5.31"8.62"5.39"	1.9kg
Projection Lens 26°	5.31"8.62"5.39"	1.7kg
Projection Lens 36°	5.31"8.62"5.39"	2kg

Illuminance data

Projection with Different Lens (take M1000R as an example）

CCT	Testing Condition	Unit	3m	5m	7m
5600K	M1000R Bare Light	Lux	4010	1650	923
	M1000R Bare Light	fc	373	153	86
	With 19°Lens	Lux	11600	3740	1860
	With 19°Lens	fc	1080	348	173
	With 26°Lens	Lux	7980	2670	1330
	With 26°Lens	fc	741	248	124
	With 36°Lens	Lux	6500	2230	1120
	With 36°Lens	fc	604	207	104
R（Red）	M1000R Bare Light	Lux	859	390	208
	M1000R Bare Light	fc	80	36	19
	With 19°Lens	Lux	2550	830	400
	With 19°Lens	fc	237	77	37
	With 26°Lens	Lux	1770	552	287
	With 26°Lens	fc	158	51	27
	With 36°Lens	Lux	1430	450	238
	With 36°Lens	fc	133	42	22
G(Green）	M1000R Bare Light	Lux	1490	625	345
	M1000R Bare Light	fc	138	58	32
	With 19°Lens	Lux	4380	1380	687
	With 19°Lens	fc	407	128	64
	With 26°Lens	Lux	2930	995	501
	With 26°Lens	fc	272	93	47
	With 36°Lens	Lux	2440	825	422
	With 36°Lens	fc	226	77	39
B(Blue）	M1000R Bare Light	Lux	524	212	121
	M1000R Bare Light	fc	49	20	11
	With 19°Lens	Lux	1550	495	249
	With 19°Lens	fc	144	46	23
	With 26°Lens	Lux	1050	356	180
	With 26°Lens	fc	98	33	17
	With 36°Lens	Lux	859	249	152
	With 36°Lens	fc	80	27	14
